CNC Syncro Press Brake Machine
CNC Synchro press brakes are designed to give more accuracy and better productivity. The controller has a facility to program the various jobs with complex bending sequence on screen. The CNC Control is used for Three Axis Control or more.
The program gives facility to bend different bending degrees; different back gauge positions & different open positions. It has a facility to save different programs and it can be reloaded as & when required. The back gauge consists of Flip-top Fingers, Ball Screw & Linear Bearing along with drive.
Range: 20MT to 600MT | Length: 1250 mm to 7000 mm
- Synchronized Ram Axes Y1 & Y2
- Back Gauge Axis X
The program gives facility to bend different bending degrees; different back gauge positions & different open positions. It has a facility to save different programs and it can be reloaded as & when required. The back gauge consists of Flip-top Fingers, Ball Screw & Linear Bearing along with drive.
Range: 20MT to 600MT | Length: 1250 mm to 7000 mm
The machine can be equipped with some high-end optional accessories like,
- Back gauge Axis X1, X2, R & Z
- Anti- Deflection units
- Special profile Hardened Dies & Punch
Product Features
- World class dedicated controller from Delemor Cybelec.
- 3 or more axis control i.e. ram axis Y1,Y2 & Back gauge axis x.
- Bend angle & Depth Mode program.
- Highly Precise press brake scale for Y1, Y2 axis.
- Close loop proportional hydraulics for ram synchronization.
- Zero leak sealing of hydraulic cylinders.
- Hardened & ground Multi “V” Die & Punch.
- Manual Anti deflection unit in punch.
- Quick release die clamps.
- Highly Precise proportional valve to control accurate beam movement.
- The power pack is supplied by Hoerbiger / Bosach –Germany.
- Back gauge consist of hardened & ground ball screw, liner motion bearings and AC servo drive for accurate position up to 0.05 mm.
